EVOSAT-6EX Power Meter for optical power measurements in Single Mode and Multi Mode
Product Code: 560EVOSAT-6EX
Inventory Status:
out of stock
EVOSAT-6EX Power Meter for optical power measurements in Single Mode and Multi Mode
Innovative and latest concept device, the new Power Meter model EVOSAT-6EX is able to perform measurements in Single
Mode and Multi Mode. Equipped with LED light, on the high resolution screen it allows easy reading of the optical signal power measurements on the scale frequencies: 850/1300/1310/1490/1550/1625. Integrated automatic shut-off. 12 month warranty and three year calibration interval.
- Model: EVOSAT-6EX display: 1310/1490/1550/1625: -50- + 26 dBm 850/1300: -40- + 26dBm
- Accuracy: ± 0.2dB
- Wavelengths: 850nm, 1300nm, 1310nm, 1490nm, 1550nm, 1625nm
- Power measurement accuracy: 0.01dB
- Linearity: ± 0.2dB
- OPM connector: 2.5mm universal
- VFL Connector: Universal 2.5mm
- VFL output (optional): 1mW or 10mW, CW and Glint
- LED light: SOS emission code
- Automatic shutdown: after 10min of inactivity (removable)
- Battery charger: yes
- Battery life: about 60 hours (OPM)
- Dimensions: 105mm x 52mm x 24mm
- Weight: about 100 gr
- Storage temperature: -20 + 60 ° C
- Operating temperature: -10 + 50 ° C
- Humidity: <90% RH
- Altitude: 0-5000m
Product code: ATL10000003
Further information in the attached product sheet
